From $350
High Flex Plus System
HI-FLEX Plus is a flexible, fiberglass reinforced, waterbased acrylic, waterproof membrane system that is applied between the substrate/sub-floor and finished flooring such as pavers, tile, vinyl sheet goods, or carpet. When used above-grade HI-FLEX is designed to prevent water damage , due to flooding, by eliminating water leaking into rooms below. When used on-grade HI-FLEX slows the vapor transmission of concrete slabs to an acceptable level so it will not affect the flooring installation.
Safety Data Sheet: View All SDS Documents
Description
HI-FLEX Plus is a flexible, fiberglass reinforced, waterbased acrylic, waterproof membrane system that is applied between the substrate/sub-floor and finished flooring such as pavers, tile, vinyl sheet goods, or carpet. When used above-grade HI-FLEX is designed to prevent water damage , due to flooding, by eliminating water leaking into rooms below. When used on-grade HI-FLEX slows the vapor transmission of concrete slabs to an acceptable level so it will not affect the flooring installation.
TECHNICAL INFORMATION
HI-FLEX has been tested in accordance with A S T M E 9 6 for Water Vapor Transmission Rate(WVTR) and Waterproofness (LWPR). Results: WVTR @ 72 hours – 15.88 g/m2/day, 3.25 lbs/1000 ft2/day. @ 360 hours – 15.76 g/m2/day, 3.23 lbs/1000 ft2/day. LWPR @ 72 hours – 41.44 g/m2/day, 8.49 lbs/1000 ft2/day – @ 360 hours – 20.32 g/m2/day, 4.16 lbs/1000 ft2/day. HI-FLEX complies with the standards for V.O.C. (Volatile Organic Compounds) for State of California as required for Waterbased Acrylic Coating under E.P.A. guidelines. Can be used with thin set mortar. See the All Deck Instructions for repair and preparation of substrate prior to installation of HI-FLEX Membrane System. Site testing of slab in accordance with VPI calcium chloride dome test to determine vapor emission is recommended before applying HI-FLEX System. Use of a clear, penetrating, non-toxic, non-silicone, non-acrylic, water-based sealer in combination with the HI- FLEX System is suggested for on-grade slabs.
ADVANTAGES
HI-FLEX will help keep down-time to a minimum because of the fast drying acrylic resins used. It will not cause a disruption of normal traffic flow in the surrounding areas during application.
WHERE TO USE
HI-FLEX is ideal for shopping malls, restaurants, multi-level residential, commercial and industrial properties. Used extensively in markets, hospitals, laboratories, factories, kitchens & bathrooms at major malls. Used at locations such as: South Coast Plaza, Del Amo Plaza, and Edward’s Air Force Base.
MATERIALS & COVERAGE RATES
HI-FLEX waterproof membrane consists of: (1) ALL DECK Laminating Resin applied over 3/4 oz. fiberglass mat, (2) HI-FLEX Resin. Coverage rates: ALL DECK Laminating Resin – 40-60 sq. ft. per gal. Fiberglass over entire surface. HI-FLEX Resin – 80-100 sq. ft. per gal.
LIMITATIONS
Not recommended for use where high water table is present. Installation of a test sample to insure compatibility is advisable. DO NOT APPLY IF AIR OR GROUND TEMPERATURE IS BELOW 50 DEGREES F.
WARRANTY
Although guaranteed to be chemically sound, HI-FLEX has no warranty.
